PLC LX5S-1616MR-(AN/DN) / 16 Digital input , 16 Digital output Relay
คุณสมบัติสินค้า:
PLC WECON LX5S Series / PLC LX5S-1616MR-(AN/DN) (Relay output) / IO: 16xDI/16xDO , Interface Port : RS422, RS485, Ethernet and 1 BD board supported.
Type
I/O Points
Output type
Power supply
หมวดหมู่ : FACTORY AUTOMATION , PLC & Modules , CPU ,
แบรนด์ : WECON
Share
| Technical information | |
| Running mode | Round scan / Interrupt |
| Programming | Instruction list / Ladder |
| Total instructions | Basic Instructions: 29 / Applied Instruction: 170 |
| Execute time | Basic Instructions: 0.03-0.08us |
| System Storage | 512Kbyte |
| Download/ Monitoring | Serial Programming Cable / Micro USB |
| External Interrupt | 6 Channels |
| Timer Interrupt | 100 Channels ; support 0.1ms interrupt |
| High Speed Input | 2 channel 150K Hz |
| 4 channel 10KHz | |
| High Speed Input AB Phase | 1 channel 100K Hz, supports 2 or 4 frequency times |
| 2 channels 10K Hz, supports 2 or 4 frequency times | |
| Holding Addresses | Adjustable |
| Storage | FLASH |
| Filter | For all X input terminals |
| Electrical data | |
| Supply voltage | AC type 85..265VAC 50..60Hz ; DC type 24VDC ±10% |
| Power consumption | AC type ≤60W ; DC type ≤30W |
| Power Outage Time | 10ms |
| Power Fuse | 250V 3.15A |
| Rush Current | AC Type <15A 5ms / AC 100V; <30A 5ms / AC 200V |
| DC type <15A 1ms / DC 24V | |
| Power Output | AC Type DC 24V 850mA ; DC type N/A |
| Backup battery | YES |
| Outputs | |
| Digital input Power Supply | DC 24V |
| Output Mode | Relay |
| Output function | dry contact |
| Output Circuit | AC 250VAC ; DC 30VDC |
| Common output current | N/A |
| Insulation | Mechanistic |
| Leak current | N/A |
| Min. Load | N/A |
| Max.Load | Resistive ; 2A point 8A COM port |
| Inductive ; 80VA | |
| General ; 100W | |
| Response Time | <10ms |
| High Speed Pulse Output | N/A |
| Operating environment | |
| Ambient temperature [°C] | 0..55 |
| Storage temperature [°C] | -20..70 |
| Ambient humidity [%RH] | 35..85 |
| Protection | IP20 |
| Tests / approvals | |
| Shock Resistance | JIS C 0040 Standard |
| Influence Immunity | Meet the IEC61000-4-4 and GB/T 17626.4 standard |
| Noise voltage amplitude 1KVP-P | |
| pulse width 10us, period 0.3 s, edge time 5ns, duration 1min. | |
| Vibration resistance | 10…50Hz (1.5mm) |
| Approval | CE , FCC , ISO9001 |
| Mechanical data | |
| Housing material | ABS |
| Mounting | DIN-Rail |
| Dimensions [mm] | 175 x 107 x 87 |
| Connection I/O | Terminal |
| Software / Interface | |
| Software | Wecon PLC Editor1/2 |
| Interface port | COM1 RS422/RS485 ; COM2 RS485 ; 1x Ethernet |
| Protocol | WECON protocol / Modbus RTU |
_______________________________________________________________________________________________
LX5S DATASHEET Download
